Sungrow SBR160 16kWh Solar Battery Storage Performance and Capacity
The Sungrow SBR160 16kWh solar battery storage consists of five series-connected 3.2 kWh modules providing 16 kWh of fully usable energy at 100 percent depth of discharge. Continuous charge and discharge current is rated at 30 A with a 10-second peak of 42 A, delivering a rated DC power of 9.60 kW and maximum charge or discharge power of approximately 10.95 kW for responsive household support. Nominal voltage is 320 V with an operating range of approximately 250 to 365 V, optimised for efficient high-voltage DC coupling with compatible hybrid inverters.
Round-trip efficiency is among the highest in its class, supporting maximised solar self-consumption with minimal energy loss during daily cycling. The complete tower measures 625 x 805 x 330 mm and weighs 180 kg, remaining practical for floor-standing indoor or covered outdoor installation. The modular design allows expansion within the same tower up to eight modules for 25.6 kWh, while up to four towers can be paralleled for larger total capacity when required.
Cell technology is lithium iron phosphate prismatic cells, cobalt-free and selected for thermal stability and long cycle life. Operating temperature supports charge from 0 to 50 degrees Celsius and discharge from minus 20 or minus 30 to 50 degrees Celsius depending on exact configuration, ensuring reliable performance across Australian climate conditions. SEIA vision for energy storage growth
Sungrow SBR160 16kWh Solar Battery Storage Compatibility Safety and Durability
Inverter compatibility centres on Sungrow hybrid inverters such as the SH series, with CAN communication enabling seamless monitoring and control. The system supports on-grid, hybrid and backup applications when paired with a suitable hybrid inverter. Multi-stage protection includes over and under voltage, over current, over and under temperature and an integrated DC breaker for enhanced system safety.
Enclosure protection is rated IP55, providing effective weather-seal protection against dust and water for indoor or covered outdoor locations. The robust modular construction is engineered for durability under temperature cycling and normal mechanical stress. Certifications include CE, CEC, IEC 62619, IEC 62040, UN38.3 and VDE 2510-50, confirming compliance with high international safety and transport standards.
Pre-shipment inspection checks verify module capacity, voltage balance, communication integrity and physical condition before dispatch. Every system is factory-tested and batch-certified so customers receive verified performance data. The stable LiFePO4 chemistry combined with multi-stage protection and the protective enclosure minimises weather-related degradation, supporting the full ten-year product warranty under normal operating conditions. Buy Sungrow SBR160 16kWh solar battery storage
Sungrow SBR160 16kWh Solar Battery Storage Delivery and Support
Insured freight delivery is arranged for all orders with full transit coverage to protect against loss or damage during transport across Australia. Signature on delivery is required so the unit is handed only to an authorised recipient. In the rare event of shipping damage a clear claim process is provided: photograph the packaging and unit on arrival, note any issues on the carrier’s delivery docket and contact Prime Solar support within the stated window for rapid assessment and resolution.
The plug-and-play modular design with no internal cabling between modules simplifies professional installation by a licensed electrician experienced with high-voltage battery systems. All units arrive ready for efficient stacking and connection. Browse the rest of the collection at https://primesolaraustralia.shop/product-category/solar-batteries/ to complete your solar energy setup with matching panels, inverters and accessories.
